Description
The WBM coil is a High-Capacity Hydronic Water Coil available as an add-on module to the Hi-Velocity System. Mainly used in chilled water applications for cooling, this coil can also be used for heating with water temperatures up to130°F (54°C). It can be installed in a variety of orientations.
The WBM module can be installed as a stand (return air base) for the air handler or as a side-mounted coil. When the desired air inlet side has been determined, the module can be adapted. The module comes ready as left to up/right orientation, but can easily be changed to a right to up/left orientation.
Matching Air Handler:
WBM-50 matching air handlers are HE-Z/HE-B/HE-50/51 HV-50/51/52 CU-51 LV-50
WBM-70 matching air handlers are HE-Z/HE-B/HE/HV-70/71 LV-70 LV-Z/LV-E-1050
WBM-100 matching air handlers are HE-Z/HE-B/HE/HV-70/71 LV-70 LV-Z/LV-E-1050
Warranty: A Five (5) Year Limited Warranty is extended on all components in products manufactured exclusively by Energy Saving Products. These components include Motors, WEG controllers, Circuit Boards, Dampers, Zoning Controls, Blowers, Motor & Blower Assemblies, Heating Coils, Chilled Water Coils, and Air Conditioning Coils. A Three (3) Year Limited Warranty is extended on Electric Strip Heaters. A One (1) Year Limited Warranty is extended on replacement parts.
